| Model | WX-186F/FA |
| Type | Single-cylinder,4-stroke air-cooled diesel engine |
| Combustion system | Directinjection |
| Bore X sttoke(mm) | 86X70/86X72 |
| Dlsplacement(cc) | 406/418 |
| Engine speed(rpm) | 3000/3600 |
| Maximum output(hp) | 9/10.0 |
| Conetinous output(hp) | 8.2/9.0 |
| Power take off | Crankshaft or camshaft(camshaft PTO rpm is1/2) |
| Starting system | Recoil or electric(optional) |
| Fuel tank capacity(L) | 5.5 |
| Lube oil capacity(L) | 1.65 |
| Dimensions LX WX H(mm) | 480X420X530 |
| Net weight(recoil)(kg) | 48 |
| Net weight(electric)(kg) | 53 |
| Fuel type | 0#,-10#,-20# |
| Lube oil type | CD Grade or SAE 10W-30.SAE 15W-40 |
| Option | Oil bath air cleaner |
