| MODEL | WX4400E | WX5500E | WX6600E | WX7700E | |||||
| GENERATOR | Frequecy(HZ) | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 |
| Rated AC output(kw) | 3 | 3.5 | 4 | 4.5 | 8 | 5.5 | 5.5 | 6 | |
| Max.AC Output(Kw) | 3.5 | 4 | 4.5 | 5 | 8.5 | 6 | 6 | 6.5 | |
| Rated AC voltace(v) | 220/380 | 110 | 220/380 | 110 | 220/380 | 110 | 220/380 | 110 | |
| Power factor(COSO) | cosΦ=1 | cosΦ=1 | cosΦ=1 | cosΦ=1 | |||||
| DC output(v) | 12V/8.3A | 12V/8.3A | 12V/8.3A | 12V/8.3A | |||||
| Phase | Single phase/3-phase | ||||||||
| Alternator | Self-excited,2-pole,single phase alternator | ||||||||
| Sterting system | Recoil or Electric | Recoil or Electric | Recoil or Electric | Recoil or Electric | |||||
| Noise level dB(at 7m) | 68-72 | 68-73 | 68-74 | 68-75 | |||||
| Fuel tank capacity(L) | 16 | 16 | 16 | 16 | |||||
| Continuous running time(h) | 11 | 10 | 7.5 | 7 | 7.5 | 7 | 7.5 | 7 | |
| DLESEL ENGLNE | Model | WX178F | WX186F | WX186F | WX186FA | ||||
| Engine type | Single-cylinder,vertical,4-stroke air-cooled Dieselengine | ||||||||
| Displacement(cc) | 296 | 406 | 406 | 406 | |||||
| Fuel | 0# or-10# light disesl oil | ||||||||
| BoreXstroke(mm) | 78X64 | 86X70 | 86X70 | 86X72 | |||||
| Lubrication oil volume(L) | 1.1 | 1.65 | 1.65 | 1.65 | |||||
| Combustion system | Direct Injection | Direct Injection | Direct Injection | Direct Injection | |||||
| PACKAGE | Dimension(LXWXH)(mm) | 840X550X680 | 920X550X680 | 920X550X680 | 920X550X680 | ||||
| NetWeiaht(Kg) | 145 | 160 | 165 | 170 | |||||
| 20GP/40GP | 60/168pcs | 60/144pcs | 60/144pcs | 60/144pcs | |||||
